Description
Product Description
Features
Long life and safety
Vertical industry integration ensures more than 6000 cycles with 80% DoD.
Easy to install and use
module
design, easy to use and quick to install.Small size, minimizing
installation time and cost Compact and stylish design suitable for your
battery packs.
Wide Application
The
LiFePO4 cells have a variety of applications. Whether it is used for
main power supply in the area without electricity or backup power supply
in the area with unstable power to deal with sudden power failure, the
system can respond flexibly. It also works well on golf cart, forlift,
club cars, e-bike etc.
Scalability
You can use in parallel or serial at the same time, and can provide required capacity and energy for your use.
Product Parameters
Typical Capacity
105Ah
Typical Voltage
3.2V
AC Impedance Resistance
<0.4mΩ
Standard charge and discharge Charge/Discharge Current
0.5C/0.5C
Standard charge and discharge Charge/Discharge Cut-off Voltage
3.65V/2.5V
Continuous Charge/Discharge Current
1C/1.5C
Pulse Charge/Discharge Ccurrent(30s)
1C/2C
Recommended SOC window
10%~90%
Charging Working Temperature
0ºC~60ºC
Discharging Working Temperature
-20ºC~60ºC
Product Application
Workshop
