Description
Product Description
Features
Long life and safety
Vertical industry integration ensures more than 6000 cycles with 80% DoD.
Easy to install and use
module
design, easy to use and quick to install. Small size, minimizing
installation time and cost Compact and stylish design suitable for your
battery packs.
Wide Application
The
LiFePO4 cells have a variety of applications. Whether it is used for
main power supply in the area without electricity or backup power supply
in the area with unstable power to deal with sudden power failure, the
system can respond flexibly. It also works well on golf cart, forlift,
club cars, e-bike etc.
Scalability
You can use in parallel or serial at the same time, and can provide required capacity and energy for your use.
Product Parameters
Item
Specification
Remark
Typical Capacity
282Ah
Temperature:25±2ºC
0.5C discharge capacity
Minimum Capacity
280Ah
Internal Impedance
0.17±0.05mΩ
By AC 1 KHZ
Nominal Voltage
3.2V
Cell Weight
≤5.45kg
contain package
End-of-charge Voltage
3.65V
At CC mode
End-of-discharge Voltage
2.5V
Charge Method
0.5C CC/CV
Max Pulse Discharge current
560A
Pulse Current width:2C Under 60 Seconds
Max Continuous Discharge current
280A
Continuous Discharge current: Under 1C
Max Pulse charge current
560A
Pulse Current width:2C Under 60 Seconds
Standard charge current
140A
0.5C
Cycle Life
≥6000 cycles
0.5C Continual Charge&Discharge( 100% DOD) Rest Capacity over 80%
Operating
Temperature
Range
Charging Temperature
0~60ºC
Recommended temperature range for long term storage is 0~+60ºC
Discharging
Temperature
-30~60ºC
Recommended temperature range for long term storage is -30~+60ºC
Storage Temperature
-30~60ºC
Recommended temperature range for long term storage is -30 ~ +60ºC
Shelf Life
3 year
Typical value from ship state
Appearance
Without break, scratch, distortion, contamination, leakage and so on
Self-discharge
≤ 3.0%/month (25±2ºC,30%SOC)
